SPECIFICATIONS

APP: X SmartHome

Audio encoding standard/bit rate: G711.A/64Kbps

Battery power detection: support, 3.4V-4.2V

Brand Name: Shunmaii

Call push notification: support (about 5s)

Certification: None

Charging interface: Type C interface

Charging power supply: DC 5V1A

Color box size: 160*90*35mm

Dingdong code: private code

Dingdong machine size: 60*44*26mm

Doorbell machine size: 85*50*26mm/3.35x1.97x1.02inch

Firmware upgrade: remote OTA

Gross weight: 1500g

High-concerned chemical: None

Infrared light control: automatic, adjustable sensitivity level

Input: High-sensitivity microphone

Intercom: Two-way voice intercom, built-in echo cancellation

Main control model: Broadcom BK7252

MicroSD card holder: not supported

Network configuration: Bluetooth-Compatible network configuration

Network protocol: TCP/IP, HTTP, TCP, UDP, DHCP, DNS, P2P, etc.

Origin: ,

Output: Built-in speaker

Passive viewing: pictures, triggered by ringing

Power supply: lithium battery 800mAh

Resolution: VGA, 640*480

Sensor: VGA CMOS Image Sensor GC0309

Sleep time: 30S

Smart Door Bell: Visual Doorbell

Standby time: about 1 Year

Storage: cloud storage, three days of rolling storage by default

Video encoding standard: MJPEG

Video frame rate: VGA@20fps

Video transmission: AES encryption

Viewing angle: 65 degrees

Voice-changing intercom: Supported

WiFi: 2.4G

Wireless Video Doorbell: Doorbell Camera

Wireless network: WiFi802.11b/g/n Wireless network

Working humidity: 95%

Working temperature: -10-45 degrees

_x000D_
_x000D_ _x000D_

_x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_

_x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ WiFi Wireless Video Doorbell IR Night Vision Doorbell Camera Two-way Audio Smart Door Bell for Home Security Alarm System _x000D_ Feature: _x000D_ 1. Advanced Wireless Video Doorbell: The i5 is a VGA network visual smart doorbell featuring a highly integrated BK7252 SOC processor. Enjoy a compact design with built-in flash, WiFi, and Bluetooth-Compatible for seamless connectivity and functionality. _x000D_ 2. High-Quality Doorbell Camera: Crafted from premium materials, this doorbell camera is practical, ensuring long-lasting performance. It offers a reliable solution for monitoring your home while withstanding the elements. _x000D_ 3. HD Video Quality: Experience crystal-clear visuals with the smart door bell's wide-angle HD video capabilities. Easily see and identify visitors at your door, enhancing your home security and peace of mind. _x000D_ 4. Wireless Convenience: This visual doorbell connects to your smartphone via WiFi, enabling two-way communication, photo capture, and recording. Stay connected with your family and enhance security with ease. _x000D_ 5. Night Vision Functionality: Equipped with a built-in light sensor, this home door bell automatically activates night vision in low-light conditions, ensuring you can see visitors clearly at night and providing added safety for your home. _x000D_ _x000D_ Specification: _x000D_ Origin: _x000D_ Main control model: Broadcom BK7252 _x000D_ Online users: Up to 9 people can share and 1 person can watch online at the same time _x000D_ Sensor: VGA CMOS Image Sensor GC0309 _x000D_ Viewing angle: 65 degrees _x000D_ Night vision: 850nm infrared fill light, effective distance 3M (laboratory environment) _x000D_ Video encoding standard: MJPEG _x000D_ Resolution: VGA, 640*480 _x000D_ Video frame rate: VGA@20fps _x000D_ Video transmission: AES encryption _x000D_ Input: High-sensitivity microphone _x000D_ Output: Built-in speaker _x000D_ Intercom: Two-way voice intercom, built-in echo cancellation _x000D_ Voice-changing intercom: Supported _x000D_ Audio encoding standard/bit rate: G711.A/64Kbps _x000D_ Network protocol: TCP/IP, HTTP, TCP, UDP, DHCP, DNS, P2P, etc. _x000D_ Wireless network: WiFi802.11b/g/n Wireless network _x000D_ WiFi: 2.4G _x000D_ Passive viewing: pictures, triggered by ringing _x000D_ Storage: cloud storage, three days of rolling storage by default _x000D_ APP: X SmartHome _x000D_ Network configuration: Bluetooth-Compatible network configuration _x000D_ MicroSD card holder: not supported _x000D_ Buttons: 2: doorbell button, reset button _x000D_ Indicator: 2: charging indicator _x000D_ Dingdong code: private code _x000D_ Power supply: lithium battery 800mAh _x000D_ Charging power supply: DC 5V1A _x000D_ Charging interface: Type C interface _x000D_ Call push notification: support (about 5s) _x000D_ Sleep time: 30S _x000D_ Battery power detection: support, 3.4V-4.2V _x000D_ Firmware upgrade: remote OTA _x000D_ Infrared light control: automatic, adjustable sensitivity level _x000D_ Working temperature: -10-45 degrees _x000D_ Working humidity: ≤95% _x000D_ Standby time: about 1 Year _x000D_ Doorbell machine size: 85*50*26mm/3.35x1.97x1.02inch _x000D_ Dingdong machine size: 60*44*26mm _x000D_ Color box size: 160*90*35mm _x000D_ Gross weight: 1500g _x000D_ _x000D_ _x000D_ _x000D_ Note: _x000D_ Due to different monitor settings and lighting conditions, the actual color of the item may vary slightly from the pictures. Thanks for your understanding! _x000D_ Please allow a 1-2 cm difference in measurements due to manual measuring._x000D_ _x000D_   _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ 1 X Wireless Video Doorbell  _x000D_ 1 X Usb Plug Ding Dong _x000D_ 1 X Type-C Charging Cable _x000D_ 1 X Installation Post _x000D_ 1 X English Instruction Manual   _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_
